ZyXEL WAC6103D-I 900Mbit/s White WLAN access point - Networking device

Enterprise-class 11ac with dual-optimized antennaThe WAC6103D-I is a high-performance 802.11ac three-stream access point offering combined data transfer rates up to 1.75Gbps with a dual-optimized antenna. The adjustable antenna provides superior performance in both ceiling- and wall-mounted deployments. User-friendly features allow for adjustment of antenna patterns via either physical switch or GUI in just seconds. No prior professional knowledge of antenna accessory selection or signal coverage fine-tuning is necessary.Ultra-slim design blends with modern interiorsThe WAC6103D-I expresses stylish functionality through its optimized radiating platform, delivering exceptional performance in only 1.26 inches height (32mm). The WAC6103D-I perfectly blends into any modern office, hotel, classroom, or café.Perfect choice of medium to high-density environmentsDesigned with dual-optimized antenna, the WAC6103D-I provides switchable signal patterns to reduce inter-floor interference. In addition, advanced Wi-Fi features such as load balancing and smart-client steering ensure a smooth, consistent, and uninterrupted wireless access experience for all users.Perfect choice for high-density environmentsDesigned with dual-optimized antenna, the WAC6103D-I provides switchable signal patterns to reduce inter-floor interference. In addition, advanced Wi-Fi features such as load balancing and smart-client steering ensure a smooth, consistent, and uninterrupted wireless access experience fo

Data transmission
Wi-Fi data rate (max)	1300 Mbit/s
Ethernet LAN data rates	10,100,1000 Mbit/s
Data transfer rate (max)	900 Mbit/s
Performance
2.4 GHz	Yes
5 GHz	Yes
Wi-Fi data rate (max)	1300 Mbit/s
Reset button	Yes
Bandwidth	5 GHz
Frequency band	2.4 - 5
VLAN support	Yes
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3ab,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u
Ethernet LAN data rates	10,100,1000 Mbit/s
Certification	FCC part 15C FCC part 15E ETSI EN 300 328 EN 301 893 LP0002 FCC part 15B EN 301 489-1 EN 301 489-17 EN55022,EN55024 EN61000-3-2/-3 EN60601-1-2 BSMI CNS13438 EN 60950-1 IEC 60950-1 BSMI CNS14336-1
Data transfer rate (max)	900 Mbit/s
Wireless LAN features
Frequency band	2.4 - 5
Networking
Internal	No
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11g,IEEE 802.11n,IEEE 802.3,IEEE 802.3ab,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u
Bandwidth
Bandwidth	5 GHz
Ports & interfaces
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	2
Security
Security algorithms	WEP,WPA,WPA2
MAC address filtering	Yes
Management features
VLAN support	Yes
Packaging data
Package width	235 mm
Package depth	246 mm
Package height	60 mm
Package weight	938 g
Certificates
Certification	FCC part 15C FCC part 15E ETSI EN 300 328 EN 301 893 LP0002 FCC part 15B EN 301 489-1 EN 301 489-17 EN55022,EN55024 EN61000-3-2/-3 EN60601-1-2 BSMI CNS13438 EN 60950-1 IEC 60950-1 BSMI CNS14336-1
Design
Placement	Ceiling, Floor, Wall
Colour of product	White
Internal	No
LED indicators	Yes
Technical details
Reset button	Yes
Indication
LED indicators	Yes
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Package width	235 mm
Width	203.9 mm
Package depth	246 mm
Depth	191.7 mm
Package height	60 mm
Weight	445 g
Package weight	938 g
Height	34.7 mm
Packaging content
Quick start guide	Yes
AC adapter included	Yes
